Disposable Bacterial Viral Filter BV
Zhejiang Haisheng Medical Device Co., Ltd.- Type：Surgical Supplies Materials
- Material：Plastic
- Ethylene Oxide Sterilization：Ethylene Oxide Sterilization
- Quality Guarantee Period：3 Years
- Group：Adult
- Logo Printing：With Logo Printing
Base Info
- Model NO.：A501-2
- Transport Package：by Sea and Air
- Trademark：Hisern Medical
- Origin：China
- Production Capacity：100, 0000
Description
Basic Info.
Model NO. A501-2 Transport Package by Sea and Air Trademark Hisern Medical Origin China Production Capacity 100, 0000Product Description
Used in anesthesia and respiratory system, our B/V Filter is designed for the protection of the patient, hospital personnel and the equipment from potential microbial contamination.Features:
• Lightweight reduces torque on tracheal connection.
• ISO connectors allow for safe and secure connections.
• Gas sampling port with cap for easy, safe monitoring of expired gases.
•ISO, CE&FDA 510K
| Description | Bacterial/Viral Filter (BV) |
| Humidity Output | N/A |
| Filtration Efficiency | BFE 99.9-99.999% VFE 99-99.99% |
| Resistance @ 30 LPM | <1.2cm H2O (BFE 99.999%, VFE 99.99%) <0.6cm H2O (BFE 99.9%, VFE 99%) |
| Resistance @ 60 LPM | <2.6cm H2O (BFE 99.999%, VFE 99.99%) <1.5cm H2O (BFE 99.9%, VFE 99%) |
| Dead space | 32ml |
| Tidal Volume Range | 250-1500ml |
| Connections | 22M/15F-22F/15M |
| Gas Monitoring Luer Port with retainer strap | Yes |
| Weight | 25±3g |
| REF | Specification | Packing | Carton size | G.W | Shelf Life |
| A501-1 Eco | Adult,BFE99.9%,VFE99% | 100pcs/carton | 37.5*30*34.5cm | Appro.4KG | 3 years |
| A501-1 | Adult,BFE99.99%,VFE99.9% | 100pcs/carton | 37.5*30*34.5cm | Appro.4KG | 3 years |
| A501-1 Pro | Adult,BFE99.999, VFE99.99% | 100pcs/carton | 37.5*30*34.5cm | Appro.4KG | 3 years |
