Portable First Aid Defibrillator (THR-MD900A)
Suzhou Thriving Medical Equipment Corp.- Application：Hospital
- Type：Portable First-Aid Defibrillator
- Size：Medium
- Use as：Portable First-Aid Defibrillator
- AC Power：110 or 220V
- Defibrillation Energy Level：0,3,5,7,10,20,30,50,100,200, 300,360 Joule(12 Step
Base Info
- Model NO.：THR-MD900A
- Complex Paddles：Adult and Pediatric
- Defibrillation Output Method：Asynchronized
- Gross Weight：11.5kg
- Rechargeable Battery：12V Lead-Acid (Li-ion, Option)
- Build-in Thermal Recorder：No
- Vehicle 12V Interface：Option
- Package Dimension：56*46*47cm
- Transport Package：Export Standard Carton
- Specification：CE and ISO
- Trademark：THR & OEM
- Origin：China
- HS Code：90189090
- Production Capacity：50000PCS,Year
Description
Basic Info.
Model NO. THR-MD900A Complex Paddles Adult and Pediatric Defibrillation Output Method Asynchronized Gross Weight 11.5kg Rechargeable Battery 12V Lead-Acid (Li-ion, Option) Build-in Thermal Recorder No Vehicle 12V Interface Option Package Dimension 56*46*47cm Transport Package Export Standard Carton Specification CE and ISO Trademark THR & OEM Origin China HS Code 90189090 Production Capacity 50000PCS/YearProduct Description
THR-MD900A Medical Portable First-aid Defibrillator-CE & ISO Quality Approved-your affordable Defibrillator
-Portable First-aid Defibrillator
-Adult and Pediatric
-Defibrillation output method: Asynchronized
Physical characteristics:
Main unit: Portable
Dimensions: L320xW205xH410
Weight: 9kg
DEFIBRILLATOR.
(1)Defibrillator type Manual, Asynchronized
(2)Energy accuracy +1%
(3) Energy selection 0, 3, 5, 7, 10, 20, 30, 50, 100, 200, 300, 360 joules (nominal at a resistance of 50)
(4)Charging time Maximum 10 seconds to 360 Joules
(5) Standard Adult/Pediatric Paddles Reusable external adult paddles (pediatric paddles integrated)
Power requirements
(a) AC Power supply: 100V~240V, 50Hz/60 Hz
(b) Vehicle Voltage (Option): DC 12V
Optional parameter
Li-ion battery: (11.1V 4Ah X2)
| Model Description | THR-MD900A Monophasic Defibrillator | THR-MD900B Monophasic Defi-Monitor | THR-MD900C Monophasic Defi-monitor | THR-MD900D Monophasic Defi-monitor |
| Rechargeable battery | 12V Lead-acid (Li-ion, option) | 12V Lead-acid (Li-ion, option) | 12V Lead-acid (Li-ion, option) | 12V Lead-acid (Li-ion, option) |
| AC power | 110 or 220V | 110 or 220V | 110 or 220V | 110 or 220V |
| Complex paddles | Adult and Pediatric | Adult and Pediatric | Adult and Pediatric | Adult and Pediatric |
| Build-in Thermal recorder | No | Option | Option | Option |
| Screen | No | 10.4 inch | 7 inch | 7 inch |
| Defibrillation energy level | 035710203050100200300360 joule(12 steps) | 02050100160250300360 joule(8 steps) | 035710203050100200300360 joule(12 steps) | 035710203050100200300360 joule(12 steps) |
| ECG/RESP | X | √ | √ | √ |
| NIBP/SPO2/TEMP/PULSE | X | √ | √ | X |
| Defibrillation output method | Asynchronized | Asynchronized /Synchronized | Asynchronized /Synchronized | Asynchronized /Synchronized |
| Vehicle 12V interface | Option | Option | Option | Option |
| Package dimension | 56×46× 47cm | 56×46× 47cm | 56×46× 47cm | 56×46× 47cm |
| Gross weight | 11.5Kg | 16.5kg | 16.5Kg | 16.0Kg |
