• Model NO.：KX0103
• Size：8fr-26fr
• Color：Transparent
• Length：9.05 Inch, 230mm
• Tip：Straight or Curved
• Transport Package：Single Tyvek Pouch
• Specification：CE ISO13485 SGS
• Trademark：QUNXING
• Origin：Changzhou, Jiangsu, China
• HS Code：9018390000
• Production Capacity：200, 000PCS,Year

Basic Info.

Model NO. KX0103 Size 8fr-26fr Color Transparent Length 9.05 Inch/ 230mm Tip Straight or Curved Transport Package Single Tyvek Pouch Specification CE ISO13485 SGS Trademark QUNXING Origin Changzhou, Jiangsu, China HS Code 9018390000 Production Capacity 200, 000PCS/Year

Product Description

1. Cannula feaures:
*stainless steel wirewound cannula body which is flexbile and kin-resistant;
*thin wall and tapered construction maximizes flow rates;
*with tip orientation line permits precise insterting;
*with vented or non-vented connector;
*straight or curved tip, with fixed or adjusted ring
*used during open heat surgery to build extracorporeal circuit

2. Size Description:

Size	Tip OD	Length	Connection Port
8FR	2.7MM	220MM	1/4''
10FR	3.3MM	220MM	1/4''
12FR	4.0MM	220MM	1/4''
14FR	4.7MM	220MM	1/4'
16FR	5.3MM	220MM	1/4''
18FR	6.0MM	230MM	3/8''
20FR	6.7MM	230MM	3/8''
22FR	7.3MM	230MM	3/8''
24FR	8.0MM	230MM	3/8''
26FR	8.7MM	230MM	3/8''

3. Cannula Details
