• Model NO.：BK-MT358S(BK-2478)
• Transport Package：Cartoon Package
• Specification：BK-MT358S(BK-2478)
• Trademark：BIOBASE
• Origin：China
• Production Capacity：50000 PCS Per Year

Model

BK-MT398A(BK-2498)

BK-MT390S(BK-2488)

BK-MT358S(BK-2478)

Mode

Automatic or Manual Modewithout intelligent sensing

Semi-automatic with intelligent sensing

Semi-automatic without intelligent sensing

Function

Sectioning, trimming, fast forward, fast backward, quick conversion; automatic retraction (except BK-MT358S).

Retraction Range

0~50μm  ( If 0 is set, retraction function is off )
5~50 (Retraction distance is optional in this range, and increment is 5μm, such as, 5, 10, 15, 25...)

/

Display

LED display:
sectioning thickness,
trimming thickness,
slice count,
slice speed.

OLED Display:
sectioning thickness, trimming thickness,
slice count.

LCD Display:
sectioning thickness,
trimming thickness,
slice count.

Sectioning Thickness Range

0.25~100μm
0.25~2.5μm   increment 0.25μm
2.5~5μm       increment 0.5μm
5.0~10μm     increment 1μm
10~30μm      increment 2μm
30~60μm      increment 5μm
60~100μm    increment 10μm

0~60μm
0~1.0μm increment 0.25μm
1~10μm  increment 1μm
10~20μm increment 2μm
20~60μm increment 5μm

Trimming Thickness Range

1~600μm
1~10μm       increment 1μm
10~20μm     increment 2μm
20~50μm     increment 5μm
50~150μm    increment 10μm
150~600μm  increment 50μm

0 ~100μm
0 ~1μm    increment 0.25μm
1 ~10μm  increment 1μm
10~20μm  increment 2μm
20~60μm  increment 5μm
60~100μm increment 10μm

Whole Layer Clearance Distance(Only for BK-MT390S)

10~6000μm
(10, 12, 15, 20.....6000,  after 15μm, the increment is 5μm)
Alarm when required slice finishes  sectioning.

Specimen Horizontal Feed

28mm

Specimen Vertical Stroke

70mm

52 mm

Specimen Holder Rotation

Any angle within 360°

Specimen Orientation

XY - 8°

Mini. Sectioning Thickness

0.25μm

Max. Specimen Size

70*70mm

50*50mm

Feed Speed

1500μm/s-3500μm/s

/

Precision

±5%

Standard Accessory

Cassette Clamp or Paraffin Block Clamp(Cassette Clamp is acquiescent))

Power Supply

AC110/220V±10%, 50/60Hz

Consumption

150W

100W

100W

External Size(W*D*H)

580*475*340mm

575*420*330mm

585*410*305mm

Package Size(W*D*H)

690*590*500mm

670*550*480mm

670*550*480mm

Gross Weight

49kg

45kg

45kg
